Architecture¶

System topology¶

flowchart TD
  subgraph Station
    scale[Weighbridge scale]
    tc[TruConnect<br/>Windows bridge]
    browser[Operator browser]
    scale -->|serial/TCP/UDP/HTTP| tc
    tc -->|local WebSocket| browser
  end

  subgraph Cluster["Kubernetes (Contabo, EU-Nuremberg)"]
    fe[truload-frontend]
    be[truload-backend]
    pg[(PostgreSQL)]
    rd[(Redis)]
    mq[(RabbitMQ)]
  end

  browser -->|HTTPS| fe
  fe -->|HTTPS| be
  be --> pg
  be --> rd
  be --> mq

  be -->|invoice push / status| pf[Pesaflow / eCitizen]
  be -->|vehicle / driver lookups| ntsa[NTSA, KeNHA]

Components¶

`truload-backend` (.NET 10)¶

Controllers and services in Controllers/ and Services/Implementations/. Major modules:

Weighing — WeighingController, AxleConfigurationController, VehicleController, DriverController. Autoweigh endpoint, capture-weights update, compliance decision.
Case / yard / prosecution — CaseRegisterController, CourtHearingController, ComplianceCertificateController, YardController, VehicleTagController.
Financial — PaymentController, InvoiceController, ReceiptController, PaymentCallbackController.
Identity / RBAC — RolesController, PermissionsController, UsersController; ApplicationRole, Permission, RolePermission.
Reporting — ReportController, SupersetController.
Configuration — SettingsController, IntegrationConfigController, AuditLogController.

Background jobs run on Hangfire: reconciliation, document generation, scheduled backups.

`truload-frontend` (Next.js 15, React 19, TypeScript)¶

Module layout in src/app/[orgSlug]/:

weighing/ — capture, tickets, tags, yard
cases/ — register, court hearings, charges
users/modules/ — user, role, station, department admin
setup/ — initial setup wizard

Cross-cutting concerns:

src/lib/offline/ — IndexedDB via Dexie + background sync (service worker) for intermittent networks
src/lib/api/ — typed API client
src/hooks/queries/ — React Query per domain
src/components/integrations/, src/components/payments/ — Pesaflow checkout dialog, reconciliation panel

TruConnect (Electron + Node)¶

Pluggable adapter model:

src/parsers/ — ZmParser, CardinalParser, I1310Parser, MobileScaleParser, CustomParser
src/input/ — SerialInput, TcpInput, UdpInput, ApiInput
src/output/ — WebSocketOutput, ApiOutput, SerialRduOutput, NetworkRduOutput
src/core/ — EventBus, StateManager, ConnectionPool
src/database/ — better-sqlite3 with migrations
src/cloud/ — two-way sync with the backend
src/simulation/ — scripted feeds for regression runs

Data stores¶

PostgreSQL 17 with pgvector — transactional data and semantic search on prior violations.
Redis — session cache, permission cache, background-job progress.
RabbitMQ (2 nodes) — async jobs, document generation, notifications.

Transaction path¶

Operator authenticates; backend issues JWT with role + permission claims.
Frontend calls the relevant module endpoints.
TruConnect streams live weight to the browser; the browser posts the capture to the backend.
Compliance engine computes axle-group aggregation, tolerance, and the overload decision.
Case register, yard entry, and prosecution records auto-create where applicable.
Prosecution generates an invoice; payment is settled via Pesaflow; a receipt is generated on callback.
Compliant reweigh triggers the auto-close cascade back to the case and yard entry.
